Pablo is a pedagogical low-speed airfoil analysis program written in MATLAB. It uses a one way coupled inviscid + boundary layer model.

The inviscid flow is solved using a Panel Method [1]. Three different kinds of singularity distributions can be used. The boundary layer equations use the inviscid flow velocity provided by the panel method, but the effect of the boundary layer on the inviscid flow is not taken into account, as in Panda [2]. The boundary layer model is described in [3]. It uses Thwaites' equations for the laminar part of the flow, and Head's equations for the turbulent part. Michel's criterion is used to locate transition. The drag coefficient is computed using the Squire-Young formula.

I am including this program on the CD-ROM as a convenience. The way to keep up-to-date with the latest version is to bookmark the Pablo website and download from there.

Pablo is maintained by

KTH- The Royal Institute of Technology
Department of Aeronautics
Stockholm, Sweden

Pablo was programmed by Christian Wauquiez in 1999. The KTH faculty advisor was Arthur Rizzi (rizzi@flyg.kth.se ).

References

  1. Katz and Plotkin : Low Speed Aerodynamics, From Wing Theory To Panel Methods. McGraw-Hill Inc., 1991
  2. Ilan Kroo : PANDA - A Program for Analysis and Design of Airfoils. © Desktop Aeronautics, 1988.
  3. Jack Moran : An introduction to Theoretical and Computational Aerodynamics. John Wiley and sons, 1984.
  4. I.H. Abbott and A.E. Von Doenhoff, Theory of wing sections, Dover Publications Inc,  NewYork, 1959
